General Features
Typical Applications
General Technical Specifications
| Model | Nominal Voltage (V) |
15 min. Rate (Watts/cell)) |
Capacity (AH) |
Internal Resistance (mOhm) |
Dimensions（mm/in） | Terminal | Weight ±4%(Kg) |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Length | Width | Height | Total Height | |||||||||||||
| mm | in | mm | in | mm | in | mm | in | Type | Position | Kg | Lbs | |||||
FP645HR |
6 |
19 |
4.5 |
15 |
70 |
2.76 |
47 |
1.85 |
101 |
3.98 |
107 |
4.21 |
T1/T2 |
A |
0.8 |
1.76 |
FP650HR |
6 |
22 |
5 |
12 |
0.9 |
1.98 |
||||||||||
FP670HR |
6 |
31 |
7 |
9 |
151 |
5.94 |
34 |
1.34 |
94 |
3.7 |
100 |
3.94 |
T1/T2 |
C |
1.28 |
2.82 |
FP690HR |
6 |
34 |
9 |
8 |
1.35 |
2.98 |
||||||||||
FP6120HR |
6 |
51 |
12 |
6 |
151 |
5.94 |
50 |
1.97 |
94 |
3.7 |
100 |
3.94 |
T1/T2 |
C |
2 |
4.41 |
FP1245HR |
12 |
19 |
4.5 |
26 |
90 |
3.54 |
70 |
2.76 |
101 |
3.98 |
107 |
4.21 |
T1/T2 |
C |
1.6 |
3.53 |
FP1250HR |
12 |
22 |
5 |
22 |
1.8 |
3.97 |
||||||||||
FP1260HR |
12 |
24 |
6 |
18 |
151 |
5.94 |
52 |
2.05 |
94 |
3.7 |
99 |
3.9 |
T2/T1 |
F |
2.1 |
4.63 |
FP1270HR |
12 |
31 |
7 |
20 |
151 |
5.94 |
65 |
2.56 |
94 |
3.7 |
100 |
3.94 |
T1/T2 |
F |
2.45 |
5.40 |
FP1290HR |
12 |
34 |
9 |
18 |
2.65 |
5.84 |
||||||||||
FP12120HR |
12 |
51 |
12 |
11 |
151 |
5.94 |
98 |
3.86 |
95 |
3.74 |
101 |
3.98 |
T2 |
F |
4 |
8.82 |
FP12180HR |
12 |
76 |
18 |
12 |
181 |
7.13 |
77 |
3.03 |
167 |
6.57 |
167/167 |
6.57/6.57 |
T3/T8 |
D |
5.7 |
12.57 |
FP12200HR |
12 |
82 |
20 |
10 |
181 |
7.13 |
77 |
3.03 |
166 |
6.54 |
166 |
6.54 |
T8 |
D |
6.3 |
13.89 |
FP12240HR |
12 |
100 |
24 |
10 |
166 |
6.54 |
175 |
6.89 |
125 |
4.92 |
125/125 |
4.92/4.92 |
T3/T8 |
D |
8.2 |
18.08 |
FP12280HR |
12 |
110 |
28 |
9 |
165 |
6.5 |
125 |
4.92 |
175 |
6.89 |
182/175 |
7.17/6.89 |
T6/T8 |
D |
9.3 |
20.50 |
LFP1233HR |
12 |
125 |
33 |
9 |
195 |
7.68 |
130 |
5.12 |
155 |
6.1 |
180/166 |
7.09/6.54 |
T7/T9 |
C |
10.5 |
23.15 |
LFP1245HR |
12 |
160 |
45 |
7.5 |
197 |
7.76 |
165 |
6.5 |
170 |
6.69 |
170/170 |
6.69/6.69 |
T4/T9 |
D |
14.2 |
31.31 |
LFP1265HR |
12 |
240 |
65 |
5.5 |
350 |
13.78 |
167 |
6.57 |
179 |
7.05 |
186/179 |
7.32/7.05 |
T5/T9 |
C |
21.5 |
47.40 |
LFP1270HR |
12 |
250 |
70 |
6 |
260 |
10.24 |
168 |
6.61 |
211 |
8.31 |
233/214 |
9.17/8.43 |
T5/T9 |
C |
22 |
48.50 |
LFP1275HR |
12 |
282 |
75 |
5.5 |
23 |
50.71 |
||||||||||
LFP1280HR |
12 |
290 |
80 |
5 |
24.5 |
54.01 |
||||||||||
LFP1290HR |
12 |
330 |
90 |
4.5 |
306 |
12.05 |
169 |
6.65 |
211 |
8.31 |
233/214 |
9.17/8.43 |
T5/T9 |
C |
29.5 |
65.04 |
LFP12100HR |
12 |
390 |
100 |
3.5 |
330 |
12.99 |
171 |
6.73 |
214 |
8.43 |
224/220 |
8.82/8.66 |
T5/T9 |
C |
32.5 |
71.65 |
LFP12100NHR FR |
12 |
403 |
100 |
4 |
330 |
12.99 |
171 |
6.73 |
214 |
8.43 |
224/220 |
8.82/8.66 |
T5/T9 |
C |
32 |
70.4 |
LFP12120HR |
12 |
425 |
120 |
3.2 |
409 |
16.1 |
176 |
6.93 |
225 |
8.86 |
225/225 |
8.86/8.86 |
T5/T11 |
C |
38 |
83.78 |
LFP12134HR |
12 |
475 |
134 |
3.5 |
342 |
13.46 |
172 |
6.77 |
280 |
11.02 |
285 |
11.22 |
T11 |
C |
43 |
94.80 |
LFP12140HR |
12 |
500 |
140 |
3.2 |
46 |
101.41 |
||||||||||
LFP12150HR |
12 |
620 |
150 |
3 |
485 |
19.09 |
172 |
6.77 |
240 |
9.45 |
242/240 |
9.53/9.45 |
T5/T11 |
C |
47 |
103.62 |
LFP12150CHR FR |
12 |
623 |
150 |
3 |
342 |
13.46 |
172 |
6.77 |
280 |
11.02 |
285 |
11.22 |
T5/T11 |
C |
47 |
103.62 |
LFP12200HR |
12 |
710 |
200 |
2.8 |
522 |
20.55 |
238 |
9.37 |
218 |
8.58 |
238/221 |
9.37/8.7 |
T5/T11 |
C |
65 |
143.30 |
LFP12250HR |
12 |
830 |
250 |
2.6 |
521 |
20.5 |
268 |
10.6 |
220 |
8.7 |
242/223 |
9.5/8.8 |
T5/T11 |
C |
75 |
165.40 |
LFP6200HR |
6 |
710 |
200 |
3 |
321 |
12.64 |
176 |
6.93 |
226 |
8.9 |
246/229 |
9.69/9.02 |
T5/T11 |
A |
32.5 |
71.65 |
We are updating the datasheet now. Pls contact the concerned person for details.
