General Features
Typical Applications
General Technical Specifications
| Model | Nominal Voltage (V) |
Capacity (AH) |
Internal Resistance (mOhm) |
Dimensions（mm/in） | Terminal | Weight ±4%(Kg) |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Length | Width | Height | Total Height | ||||||||||||
| mm | in | mm | in | mm | in | mm | in | Type | Position | Kg | Lbs | ||||
LFP6200T |
6 |
200 |
2 |
321 |
12.64 |
176 |
6.93 |
226 |
8.9 |
246/229 |
9.69/9.02 |
T5/T11 |
A |
32 |
70.55 |
FP1270T |
12 |
7 |
28 |
151 |
5.94 |
65 |
2.56 |
94 |
3.7 |
100 |
3.94 |
T1 |
F |
2.35 |
5.18 |
FP12120T |
12 |
12 |
19 |
151 |
5.94 |
98 |
3.86 |
95 |
3.74 |
101 |
3.98 |
T2 |
F |
3.6 |
7.94 |
FP12180T |
12 |
18 |
16 |
181 |
7.13 |
77 |
3.03 |
167 |
6.57 |
167/167 |
6.57/6.57 |
T3/T8 |
D |
5.45 |
12.02 |
FP12240T |
12 |
24 |
14 |
166 |
6.54 |
175 |
6.89 |
125 |
4.92 |
125/125 |
4.92/4.92 |
T3/T8 |
D |
7.9 |
17.42 |
LFP1233T |
12 |
33 |
10 |
195 |
7.68 |
130 |
5.12 |
155 |
6.1 |
180/166 |
7.09/6.54 |
T7/T9 |
C |
10.5 |
23.15 |
LFP1240T |
12 |
40 |
8.5 |
197 |
7.76 |
165 |
6.5 |
170 |
6.69 |
170/170 |
6.69/6.69 |
T4/T9 |
D |
13.5 |
29.76 |
LFP1265T |
12 |
65 |
6 |
350 |
13.78 |
167 |
6.57 |
179 |
7.05 |
186/179 |
7.32/7.05 |
T5/T9 |
C |
22 |
48.50 |
LFP1260T |
12 |
60 |
7 |
260 |
10.24 |
168 |
6.61 |
211 |
8.31 |
233/214 |
9.17/8.43 |
T5/T9 |
C |
21 |
46.30 |
LFP1270T |
12 |
60 |
6.5 |
23 |
50.71 |
||||||||||
LFP1280T |
12 |
80 |
5.5 |
25 |
55.12 |
||||||||||
LFP1290T |
12 |
90 |
5.5 |
306 |
12.05 |
169 |
6.65 |
211 |
8.31 |
233/220 |
9.17/8.66 |
T5/T9 |
C |
28 |
61.73 |
LFP12100T |
12 |
100 |
4.5 |
330 |
12.99 |
171 |
6.73 |
214 |
8.43 |
224/220 |
8.82/8.66 |
T5/T9 |
C |
32 |
70.55 |
LFP12120T |
12 |
120 |
4 |
409 |
16.1 |
176 |
6.93 |
225 |
8.86 |
225/225 |
8.86/8.86 |
T5/T11 |
C |
37 |
81.57 |
LFP12150T |
12 |
150 |
3.5 |
485 |
19.09 |
172 |
6.77 |
240 |
9.45 |
242/240 |
9.53/9.45 |
T5/T11 |
C |
46 |
101.41 |
LFP12200T |
12 |
200 |
3 |
522 |
20.55 |
238 |
9.37 |
218 |
8.58 |
238/221 |
9.37/8.7 |
T5/T11 |
E |
65 |
143.30 |
LFP12250T |
12 |
250 |
2.6 |
521 |
20.51 |
269 |
10.59 |
220 |
8.66 |
242/223 |
9.53/8.78 |
T5/T11 |
E |
78 |
171.96 |
LFP12100AFTHT |
12 |
100 |
6.5 |
395 |
15.55 |
110 |
4.33 |
286 |
11.26 |
286 |
11.26 |
T9/M6 |
E |
31 |
68.2 |
LFP12150FTHT |
12 |
150 |
5 |
551 |
21.69 |
110 |
4.33 |
287 |
11.3 |
287 |
11.3 |
T11/M8 |
E |
48 |
105.6 |
We are updating the datasheet now. Pls contact the concerned person for details.
